Description
| Product Attribute | Attribute Value |
| Product Category: | Logic Gates |
| Logic Function: | NAND |
| Logic Family: | 74HC |
| Number of Gates: | 4 Gate |
| Number of Input Lines: | 8 Input |
| Number of Output Lines: | 4 Output |
| High-Level Output Current: | – 5.2 mA |
| Low-Level Output Current: | 5.2 mA |
| Propagation Delay Time: | 7 ns |
| Supply Voltage – Max: | 6 V |
| Supply Voltage – Min: | 2 V |
| Minimum Operating Temperature: | – 40 C |
| Maximum Operating Temperature: | + 125 C |
| Package/Case: | PDIP-14 |
| Function: | NAND |
| Logic Type: | Quad NAND Gate |
| Operating Supply Voltage: | 2 V to 6 V |
